1.Install USB drivers into your PC.

2.Connect a USB cable between your PC and the USB port on the rear panel of the codec.

3.From the codec Home screen navigate to Settings > Unit > USB and press the button to display the USB address details configured into your codec.

4.Open your web browser and type the USB address of your codec into the address bar of your browser, i.e. http://169.254.x.y (the last 2 blocks of digits are the USB address details unique to your codec).

5.Refresh the browser and the web-GUI should launch automatically. Note: if it doesn't launch automatically please see Installing USB Drivers for more info.

6.When you launch Toolbox for the first time an authentication dialog prompts you to enter the user name "admin" and password "password" to login, then click the OK button. Tieline highly recommends changing the password (see Security and Changing the Default Password). This will provide better network security to maintain reliability during live broadcasts.
